Advanced 1500T Energy-saving Aluminum Extrusion Machine Press For Industrial Profiles

The 1500T advanced industrial energy-saving aluminum extrusion press is engineered for continuous, high-volume output of large and complex aluminum profiles while remaining simple to operate. A 1500 metric ton pressing force drives billets of Φ152mm up to 900mm long through a Φ350mm die cavity, and servo-driven hydraulics hold extrusion speed within ±0.1mm so wall thickness and surface finish stay consistent from the first billet to the last.

The short-stroke back-loading frame adds 30% more rigidity than a conventional design, while removing the gasket circulation circuit shortens reaction time and cuts line power consumption by 15%. Total installed power sits at 300KW on a 105-ton base, keeping energy cost per finished ton low. Structural, automotive, and general industrial aluminum extrusions all run comfortably within its range, and a single operator can handle die changes, tonnage settings, and daily checks without specialist training.

• The extrusion stroke is shorter than conventional extruders, reducing frame opening and increasing stress frame rigidity by 30%.
• Reduced main side cylinder volume decreases hydraulic oil usage, improving speed and pressure control accuracy.
• Elimination of the gasket circulation system reduces reaction operation time and power consumption by 15%.
• Servo motor-driven translation manipulator further reduces non-extrusion time by 15%.

Our hydraulic aluminum extrusion machine serves multiple industries including construction, industrial trade, new energy, and photovoltaic sectors. The aluminum profiles produced have diverse applications:

• Roofs, walls, doors, and windows — durable and lightweight structural components
• Frames and reticulated shell structures — strong support for complex designs
• Grid structures and glass curtain wall support systems — robust building facades
• Awnings and pedestrian bridges — functional outdoor solutions
• Interior and exterior decorative panels, partitions, and ceilings — aesthetic enhancements
• Railings and handrails — safety with modern design
• Store containers and construction formwork — versatile assembly solutions

• Key components (container, extrusion pad, shear blade, ingot feeder) feature mature designs with low failure rates.
• Minimal impact and vibration reduce the likelihood of oil leakage.
• Quick responsiveness and high efficiency with reduced non-extrusion time.
• High precision with ±0.1mm extrusion speed control accuracy.
• Highly automated operation supports intelligent production with reduced operator skill requirements.
